H190 Plastic frame lcd monitor

4:3 aspect ratio


1280*1024 definition

Full interfaces of VGA+AV+BNC+HDMI or VGA only


  • Certification: FCC, CE, RoHS Directive-compliant, CCC



  • Mainly used in industrial endoscope, video microscope, industry Smooth degree of coplanar detector, dimensional detector, hot-press BGA rework station, Laser engraving equipment, Laser marking machine, The rocker camera security, video surveillance, POS cash register system and other similar areas.


  • Model: H190-B


  • Display: 19” TFT High Definition Digital monitor (4:3)
  • Resolution: 1280*1024 pixels
  • Luminance: 300 cd/m²
  • Contrast ratio: 450:1
  • Input voltages: 110 to 240V AC
  • Output voltage: 12V DC
  • Operating temperature: 0 to 50°C
  • Humidity temperature: 0-85% at 40°C (non-condensing)
  • Storage temperature: -20 to 60°C
  • Frame color: Black
  • Interface:VGA+AV+BNC+HDMI
  • Assembling:  With stand or VESA wall mount
  • Product size: 416*345*40 mm
  • Can be with touch function, see details in touch monitor H190-TB

  • Accessories:


    Warranty Card, Manual, VGA cable, Power adapter, Remote controller and Plastic stand.
