H97-RT 1024*768 9.7 inch capacitive touch monitor with G+G touch panel

H97-RT 1024*768 9.7 inch capacitive touch monitor with G+G touch panel

Projected capacitive touch 9.7 inch monitor with max touch 10 points; 1024*768 Consumer ILITEK touch; G+G structure; True-flat screen; VESA mount or open frame; VGA+AV+BNC+HDMI+TOUCH
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Introduction
  • Specification
  • Accessories

9.7 inch projected capacitive touch monitor

Max touch 10 points

1024*768

Consumer ILITEK touch

G+G structure

True-flat screen

VESA mount or open frame

VGA+AV+BNC+HDMI+USB for TOUCH

    • Model: H97-RT
    • Display: 9.7” TFT High Definition capacitive touch monitor (4:3)
    • Resolution: 1024*768 pixels
    • Luminance: 250 nits
    • Contrast ratio: 500:1
    • Power supply: 12V DC
    • Response time: 6ms
    • Viewing angle: 130°/140°
      • Touch technology: ILITEK touch
    • Product size: 23.8*18.8*3.4 cm
    • Interface: VGA+AV+BNC+HDMI+Touch
    • Material: true flat tempered glass screen, aluminum bezel with metal housing



    • Touch panel: G+G
    • Surface hardness: 7H
    • Transparency: >90%±5%
    • Operating temperature: 0 to 50°C/20%-80%(non-condensing)
    • Humidity temperature: 0-85% at 40°C (non-condensing)
    • Storage temperature: -20 to 60°C/5-95%(non-condensing)
    • Storage humidity: 5%~95%
    • Connection Type: USB
    • Response time: <10ms
    • Operation voltage: 3.3V-3.6V DC
    • Max supported points : 10
    • System supported: Windows XP/7/8/10, Android, Linux










  • Screen: tempered glass
  • Shell material: Aluminium
Accessories: VGA cable, power adapter, manual and VESA wall mount kit.
