H104A-T 10.4-inch HD touch screen LCD monitor display

H104A-T 10.4-inch HD touch screen LCD monitor display

10.4" plastic touch screen TFT LCD Display, compact and convenient,fit for POS systems and terminals.With VGA and USB ports.
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Thumbnail 2
  • Introduction
  • Specification
  • Accessories

10.4" plastic touch screen TFT LCD Display, compact and convenient,fit for POS systems and terminals.With VGA and USB ports.

Interface: VGA/AV interface, USB port for driver

Optional: BNC input

Language: Chinese, English, Italian, Spanish, German, French, Japanese, Korean

Certification: FCC, CE, ROHS,CCC

Display Parameters

Aspect Ratio

4:3

Contrast Ratio 350:1 Panel Type LCD
Display Area 211.2×158.4mm Brightness 400cd/㎡ Backlight CCFL
Resolution 800×600 Viewing Angle 100°/120°


Screen Color 262K Response Time 35ms

Specification

Installation Stand  Frame color Black Product Dimensions 254×210×37mm
Power input/output 110V to 240V input, 12V output Operating temperature -10~60℃ Humidity temperature 0~80%@50℃ ( non-condensing )
Storage temperature -20~70℃ Box Packing Dimensions

348×259×75mm


Touch Type 4-wire resistive(5-wire optional) Touch Interface USB/RS232
Accessories: Manual, Warranty card, Stand, AV cable, VGA cable, USB cable, Remote controller, Touch pen, Driver disk, Power supply.
